Hello everybody, this is what I've been working on in between cold weather and the flu. I had it blued
yesterday hope it come's out right.
















eastslope

New Member
Joined
Jan 16, 2008
Messages
1,008
Location
Conrad, MT
#2
Now that is really cool. Dumb question, how did you get the gun white like that? Paint, China White? That's a whole lotta area to cover. Thanks for showing, Seth

Joined
Feb 8, 2008
Messages
99
Location
Monroe, NC
Thread starter #3
Thanks Seth, the white is just flat white spray paint. You can draw and erase for days on it. To remove it
use Acetone, the full strength not the finger nail kind.

Joined
Feb 8, 2008
Messages
99
Location
Monroe, NC
Thread starter #7
Hey Darcy, thanks for the compliment. I used hammer and chisel and had a little rough cuts in certain
areas. I think it might have been because I had a lot of vibration when I was cutting or the tool was
getting dull. But it was ok pretty much.


Arnaud Van Tilburgh

New Member
::::Pledge Member::::
Joined
Oct 3, 2008
Messages
4,203
Location
Belgium
#8
Tony thanks for sharing, nice to see the different steps.
I understand engraving is also new for you as it is for me.
Never tried hammer and chisel, perhaps it is harder than using the power tools.

If I may say so, your design looks quite big, perhaps it is to avoid the little details, but I think cutting the leavers so big, looks like small leaves with magnification, so perhaps cutting smaller leaves and scrolls could have looked better as than you don' need much shadow lines and one see the mistakes less as it is smaller.

Did you first tried it on a practice plate?

arnaud


D.Ellis

New Member
Joined
Mar 29, 2007
Messages
97
Location
Fort Fraser BC Canada
#9
Thanks Tony. Those 870's are a pretty big canvas and quite affordable too. I may have to pick one up to try. From what I have heard the sides can be a bit springy to cut without some sort of support inside the action. That may have been why you found it a bit rough in certain areas. You certainly made for a fine looking 870 though with that design.......and not a clone of anyone elses work either:thumbs up:. Hope to see the pics of it blued soon.
Darcy:)


Marcus Hunt

New Member
::::Pledge Member::::
Joined
Nov 9, 2006
Messages
1,788
Location
The Oxfordshire Cotswolds, England
#10
Hi Tony, thanks for posting this; you certainly took on a huge canvas! The good points are that you got the growth of the scrolls correct.

Hammer and chisel work is not easy and takes many hours of practice to get it to look right. For inspiration from this type of work look at pictures of guns from continental Europe, especially Belgium. Your vise needs to be heavy too, especially for something this size. If it isn't you'll constantly be fighting the vise's will to tip over as you strike the chisel and it's not easy with both hands full to control the vise as well. With H&C it's well worth experimenting with standing up and 'walking around' your vise. This will help prevent all the elbows in your scrolls.

Arnaud is correct in pointing out that the scrolls are too large for the design. The larger the scroll the more difficult it is to fill it with shading. The problem with such a big 'canvas' is how to fill it. The novice's approach is often big action = big scrolls. Wrong! Big action = more scrolls, not larger ones. This means your designing needs to be spot on. Again, back to the drawing board and get that pencil and paper out. Do study other people's scroll and read Ron's book on scroll design thoroughly until you understand it.

Sorry to be picky but I think you need some tips.

Joined
Feb 8, 2008
Messages
99
Location
Monroe, NC
Thread starter #11
Thanks for all the compliments and suggestions. The scroll work is the size I was going for, because I
was taken some of the pattern off of a friends western holster. The pattern did not flow like I wanted so
I left some of the tendrils and just started drawing and the rest just came out the way it came out.
A lot of the people around here like the bigger scrolls kinda like the western bright cut buckles.
I have done the regular size and have done English and Belgian scroll when I was in school and intend to
do some more on some other pieces some time. Maybe when I can get an air powered tool and not have all
the slips I had in school. It's hard to make a straight line look like a tendril. :)


monk

Moderator
Joined
Feb 11, 2007
Messages
8,971
Location
washington, pa
#12
this is one of the first centerfire guns i ever did. seems to me your design looks far better than mine. i was totally intimidated by the sizeof the beast ! like you, i recall doing very large scroll. the client didn't want to hear of extra bucks for smaller detailed work !
